技術(shù)參數(shù)

◎規(guī)格：端鈕盒銅條，小A(8×10.5)、中A(9×11、10×12)、

   大A(11×13)

◎脈沖信號線：2、4、6、8線或2、4插片

◎電流配置：5（30）A帶1-8組輔助端口

                     10（60）A帶1-8組輔助端口

                     20（100）A帶1-8組輔助端口

◎說明：出口型表，防塵防潮設(shè)計，密封性佳，端鈕盒外置，另

    可配防竊蓋。

TECHNICAL PARAMETERS

◎Specifications: copper bar of terminal box, small A(8×10.5), middle

    A (9×11,10×12),large A(11×13)

◎Pulse signal lines:2,4,6,8 lines or 2,4 plug-in pieces

◎Current configuration: 5(30)A with 1-8 sets of auxiliary ports

                                       10(60)A with 1-8 sets of auxiliary ports

                                       20(100)A with 1-8 sets of auxiliary ports

◎Note: export-type meter with dust-proof design, good sealing and

    external terminal box, and anti-theft cover can be equipped optionally.
